Mimaki JV100-160
Brand : Mimaki
Tax excluded. Shipping calculated at checkout
Product Information
The JV100-160 is an affordable professional-grade eco-solvent roll-based model. Perfect for high-quality fine art reproduction, vehicle wrap printing, and more.
- Available in 64” with print speeds up to 677 Sq Ft/Hr
- Eco-solvent: New AS5 Ink 4 color and eight color options, including Orange and Light Black inks
- NEW Dot Adjustment System (DAS) automatically aligns to ensure consistent quality and repeatability
- Nozzle Check Unit (NCU), automatically monitors printhead performance and detects clogged nozzles
- The Nozzle Recovery System (NRS), automatically substitutes unproductive nozzles, avoiding unnecessary downtime and poor image quality
- NEW, easier-to-use RIP software, RasterLink7, reduces RIP time by 25%.
Our Core Technologies
 |
Over Cut |
 |
Zero Margin Mark |
 |
ID Cut |
 |
Continuous Mark Detect |
 |
Variable Dot Technology |
 |
Segment Mark |
 |
Mimaki Advanced Pass System (MAPS) |
 |
Nozzle Recovery System |
APPLICATIONS
Specifications
| Printhead |
Two staggered on-demand |
| Print Resolutions |
360 dpi, 540 dpi, 600 dpi, 720 dpi, 900 dpi, 1080 dpi, 1,200 dpi |
| Print Speed (4 Color Mode) |
677.05 |
| Maximum Print Area |
63.3″ (1610.0 mm) |
| Maximum media width |
63.8″ (1620 mm) |
| Maximum Media Thickness |
up to 0.04″ (1 mm) |
| Maximum Media Weight |
up to 99.2 lbs |
| Ink Type |
U.S. & Canada- |
| Ink Package Size |
600ml or 2000ml |
| Interface |
1000 Base-T Ethernet cable or USB2.0 cable |
| Power Supply |
AC100~120V/ 200~240V±10%, 50/60Hz±1Hz |
| Operational Environment |
Temperature 20° – 30°C |
| Dimensions (W × D × H) |
3,775mm (12.38ft) or more (Machine size: 2,775mm(9.1ft)) 2,700mm or more (Machine size: 700mm(2.29ft)) |
| Weight |
166kg (366lb) |
- DOWNLOAD BROCHURE JV100-160, CLICK HERE
| Solvent ink (AS5) | Cyan | Magenta | Yellow | Black | Light Cyan | Light Magenta | Light Black | Orange |
|---|---|---|---|---|---|---|---|---|
| 600ml Eco-Cartridge | I-AS5-C-60-1 | I-AS5-M-60-1 | I-AS5-Y-60-1 | I-AS5-K-60-1 | I-AS5-LC-60-1 | I-AS5-LM-60-1 | I-AS5-LK-60-1 | I-AS5-OR-60-1 |
| 2L MBIS Pack | I-AS5-C-2L-1 | I-AS5-M-2L-1 | I-AS5-Y-2L-1 | I-AS5-K-2L-1 | I-AS5-LC-2L-1 | I-AS5-LM-2L-1 | I-AS5-LK-2L-1 | I-AS5-OR-2L-1 |
| Solvent ink (SS21) | Cyan | Magenta | Yellow | Black | Light Cyan | Light Magenta | Light Black | Orange |
|---|---|---|---|---|---|---|---|---|
| 600ml Eco-Cartridge | SS21-C-60 | SS21-M-60 | SS21-Y-60 | SS21-K-60 | SS21-LC-60 | SS21-LM-60 | SS21-LK-60 | SS21-OR-60 |
| 2L MBIS Pack | SPC-0588C | SPC-0588M | SPC-0588Y | SPC-0588K | SPC-0588LC | SPC-0588LM | SPC-0588LK | SPC-0588OR |
