Mimaki UJV100-160 Plus
Brand : Mimaki
Tax excluded. Shipping calculated at checkout
Product Information
Mimaki UJV100-160 Plus
Sale price$14,995.00 USD
Regular price$17,844.00 USD (/)
Product Information
Productivity And Versatility At An Entry-Level Price
The UJV100-160Plus is a competitively priced UV-LED roll-based printer with many productivity features in higher-end models. It features Mimaki instant-dry UV-LED inks that adhere to various media, including paper, PET film, fabric, vinyl, and more -making post-printing handling and finishing effortless. UV-LED lamps instantly cure the inks, dramatically increasing printing speed and efficiency. This multi-purpose machine is suited for various applications while keeping costs low.
- Backlit applications utilizing Multiple-layer prints
- New features allow for the reduction of ink consumption by up to 50% while maintaining the color balance of the original design.
- It instantly cured prints for a shorter turnaround time and no waiting to laminate.
- With a maximum power consumption of 0.5kW, the UJV100-160Plus consumes less than 20% of the power of eco-solvent and latex printers in the market (approximately)
- Eco-friendly UV-LED six-color ink set in 1-liter bottles: C, M, Y, K, White, Clear
- Dot Adjustment System (DAS) automates dot position and feeding corrections, reducing manual intervention and workflow interruptions.
Our Core Technologies
Mimaki Advanced Pass System (MAPS)
Nozzle Recovery System
Nozzle Check Unit
Applications
The applications supported include posters, banners, backlit signs, retail signage, vehicle exteriors, artwork, promotional displays, wallpaper, and more. A UV-LED printing machine can work with various materials, such as plastic, wood, glass, metal, foam core, textiles, and leather, allowing limitless applications.
Specifications
| Printhead |
Two on-demand piezo heads, staggered layout |
| Print Resolutions |
360 dpi, 720 dpi, 900 dpi, 1200 dpi |
| Maximum Print Area |
63.4″ (1610.0 mm) |
| Maximum media width |
63.8″ (1620 mm) |
| Maximum Media Thickness |
up to 1 mm |
| Maximum Media Weight |
up to 45 kg |
| Ink Type |
U.S. & Canada- LUS-170 |
| Ink Package Size |
1L bottle |
| Interface |
Ethernet 1000 BASE-T, USB2.0 Hi-Speed |
| Power Supply |
AC100~120V/200~240V±10% 50/60Hz±1Hz |
| Operational Environment |
Temperature 20° – 30°C |
| Dimensions (W × D × H) |
109.3 x 27.6 x 58.1″ (2775 x 700 x 1475 mm) |
| Weight |
368.2 lb (167 kg) |
| Options |
Ionizer / Level foot / Lift-up block |
| UV Curable Ink (LUS170) | Cyan | Magenta | Yellow | Black | White | Clear |
|---|---|---|---|---|---|---|
| 1L Bottle | LUS17-C-BA | LUS17-M-BA | LUS17-Y-BA | LUS17-K-BA | LUS17-W-BA | LUS17-CL-BA |
| UV Curable Ink (LUS210) | Cyan | Magenta | Yellow | Black | White | Clear |
|---|---|---|---|---|---|---|
| 1L Bottle | LUS21-C-BA | LUS21-M-BA | LUS21-Y-BA | LUS21-K-BA | LUS21-W-BA | LUS21-CL-BA |
