}Ricoh GEN4L MH2620 Printhead 15pl | Hose Barb D.Gen Teleios Artrix GTII
Brand: Ricoh
Tax excluded. Shipping calculated at checkout
Availability: In stock
,%20a%2015%E2%80%9345%20pl%20drop%20range,%2030%20kHz%20jet...
){kind=link}
The Ricoh GEN4L MH2620 is a genuine original industrial inkjet printhead for oil-based, water-based, solvent, and UV ink applications. With 384 nozzles (2 × 192), a 15–45 pl drop range, 30 kHz jetting frequency, integrated heater and thermistor, and a 100 billion actuation service life, it is engineered for long-running production environments. This listing is the hose barb ink connection variant — the hose barbs can be removed and replaced with O-rings if needed. Every MH2620 we sell at Digiprint USA is 100% genuine original Ricoh Japan.
Critical Compatibility Warning — GEN4L vs GEN5
The MH2620 GEN4L is not compatible with the d.gen Teleios Grande G5 or d.gen Teleios Grande/H6. These newer printers use the Ricoh GEN5 printhead (PPHRI18045) — a completely different head platform. Installing the MH2620 in a GEN5-only printer will not work. Always confirm your printer generation before ordering. Contact our team if unsure.
Technical Specifications
| Specification | Detail |
|---|---|
| Model | Ricoh GEN4L MH2620 |
| Total nozzles | 384 (2 × 192 nozzles) |
| Nozzle spacing | 0.1693 mm |
| Nozzle plate surface | Non-wet coating |
| Native drop volume | 15 pl |
| Drop volume range | 15 – 45 pl |
| Max jetting frequency | 30 kHz |
| Piezo type | D33 Stacked PZT |
| Temperature control | Integrated heater and thermistor |
| Operating temperature | Up to 80°C |
| Ink compatibility | Oil, water-based, solvent, UV-curable inks |
| Ink connection | Hose barb (removable — can convert to O-ring configuration) |
| Head materials | SST, Ni, Epoxy Adhesive (direct ink contact) |
| Dimensions (excl. cables) | 13.2 × 120 × 75.5 mm |
| Service life | 100 billion actuations per nozzle |
| Country of origin | Japan |
| Warranty | Manufacturer warranty included |
| Condition | 100% genuine original Ricoh, brand new |
GEN4L MH2620 vs MH2820 — Which Do You Need?
| Spec | MH2620 (this listing) | MH2820 |
|---|---|---|
| Generation | GEN4L | GEN4L |
| Native drop | 15 pl | 27 pl |
| Drop range | 15 – 45 pl | 27 – 80+ pl |
| Best for | Finer detail — higher resolution output | Denser coverage — higher ink laydown |
Always confirm which GEN4L variant your printer's service documentation specifies. Contact our team for confirmation before ordering.
About the Hose Barb Connection
This MH2620 ships with hose barb ink inlet connectors — the standard connection for the D.Gen Teleios and AmicaSystems PA32 platforms. If your printer's ink supply system uses O-ring (push-fit) connectors instead, the hose barbs can be removed from the head to expose the O-ring ports. Contact our team if you need to confirm the correct ink connection type for your printer before ordering.
Compatible Printers
This printhead is compatible with the following printers:
⚠️ Not compatible with:
d.gen Teleios Grande G5 | d.gen Teleios Grande/H6 — these use the Ricoh GEN5 printhead.
Warranty Notice
Due to the sensitive nature of industrial inkjet printhead components, we cannot accept returns, exchanges, or refunds once the printhead has been installed. All sales are final. Contact our team to confirm compatibility before ordering.
Why Buy from Digiprint USA
• 100% genuine original Ricoh MH2620 GEN4L — not compatible, not refurbished
• Manufacturer warranty — sealed original Ricoh packaging
• In stock in Doral, Miami FL — same day shipping before 2PM EST
• Ideal for Latin American D.Gen and AmicaSystems print shops using Miami freight forwarders
• Free technical support — we confirm GEN4L vs GEN5 and MH2620 vs MH2820 for your printer before you order
View our full range of genuine Ricoh industrial printheads stocked by Digiprint USA.
Frequently Asked Questions
Will this MH2620 work in my d.gen Teleios Grande G5?
No — the d.gen Teleios Grande G5 and Teleios Grande/H6 use the Ricoh GEN5 printhead (PPHRI18045), which is a completely different platform. The MH2620 GEN4L is only for the original d.gen Teleios (TJ-2600), Teleios Grande (TJ-3333 / 3333TX), Teleios XL (XL2600), Artrix GTII, and AmicaSystems PA32. Check your printer's service documentation to confirm the generation before ordering.
What is the difference between MH2620 and MH2820?
Both are Ricoh GEN4L heads in the same physical format. The MH2620 has a 15 pl native drop (15–45 pl range) suited to finer detail output. The MH2820 has a 27 pl native drop for denser ink laydown. Always check your printer's service documentation to confirm which drop size variant is specified.
Can the hose barbs be removed for O-ring connection?
Yes — the hose barbs on the MH2620 are removable. If your printer's ink supply manifold uses O-ring push-fit connections rather than hose barb fittings, the barbs can be removed to expose the O-ring ports on the head body. Contact our team to confirm the correct connection type for your printer before ordering.
Do you ship Ricoh GEN4L MH2620 printheads to Latin America?
Yes — same day shipping from our Doral, Miami FL warehouse. Our Miami location is ideal for Latin American D.Gen and AmicaSystems print shops using freight forwarders in the Doral area.
